CS1642A / CS1644A User Manual
30
HSM Summary Table
After invoking HSM (see page 24), key in one of the following keys to perform
the corresponding function:
Key Function
[F1] Sets the keyboard and mouse to SPC mode so that it can work
under special operating systems as a standard (104 key)
keyboard and mouse.
[F2] Enables Mac keyboard emulation.
[F3] Enables Sun keyboard emulation.
[F4] Print the switch’s current settings via a text editor or word
processor.
[F5] Performs a USB keyboard and mouse reset.
[F6] [n][n] [Enter] Sets the keyboard language layout. Where nn is a two digit
number that represents the keyboard language code (US
English: 33, French: 08, Japanese: 15).
[F10] Automatically detects and sets the keyboard operating platform.
[B] Toggles the beeper On and Off.
[C] Change the front panel pushbutton combo (holding pushbuttons
1 and 2) to a hotkey of your choice.
[C] [2] Change the front panel pushbutton combo (holding pushbuttons
3 and 4) to a hotkey of your choice (CS1644
A only).
[D] Invokes Video DynaSync, ATEN’s exclusive technology that
eliminates boot-up display problems and optimizes resolution
when switching between ports.
[E] Toggles the Power-on-Detection function on/off.
[H] Toggles between the default and alternate HSM invocation keys.
[M] Toggles between mouse emulation enable and disable.
[N] Toggles between keyboard emulation enable and disable.
[R] [Enter] Resets the hotkey settings to their default status.*
[T] Toggles between the default and alternate Port Switching keys.
[u] [p] [g] [r] [a] [d]
[e] [Enter]
Invokes Firmware Upgrade Mode.*
