ATEN Master View CS1308 User Manual

Chapter 2. Hardware Setup
9
Rack Mounting – Front
1. Remove the screws from the left and right side panels near the front of the
switch (2 screws total).
2. Use the M3 x 8 Phillips hex head screws supplied with the rack mount kit
to screw the rack mounting brackets onto the side panels near the front of
the unit.
(Continues on next page.)

ATEN Master View CS1308 Specifications

General

Device Type	KVM Switch
Ports	8
Max Resolution	2048 x 1536
Video Bandwidth	350 MHz
Daisy Chain	No
Number of ports	8
Console Connections	1
Operating Temperature	0 - 50°C
Storage Temperature	-20 - 60°C
Humidity	0 - 80% RH, Non-condensing
Connectors	8 x SPHD-15 Female (Yellow)
Computer Connections	8
Console Ports	1 x SPHD-15 Female
Video Resolution	2048 x 1536
Power Consumption (DC)	5W
Dimensions (mm)	437.2 x 160 x 44 mm
Power Consumption (AC)	5W
