Connection Tables
The following tables indicate the relationship between the number of switches
and the maximum number of computers that they can control.
CS1308 to Compatible 8-Port Switches
CS1308 to Compatible 16-Port Switches
CS1316 to Compatible 8-Port Switches
CS1316 to Compatible 16-Port Switches
Switches Computers Switches Computers Switches Computers
1 8 429750
215536857
322643964
Switches Computers Switches Computers Switches Computers
1 8 453798
2235688113
3386839128
Switches Computers Switches Computers Switches Computers
11675813100
22386514107
33097215114
4 37107916121
5 44118617128
6 511293 – –
Switches Computers Switches Computers Switches Computers
1 16 7 106 13 196
2 31 8 121 14 211
3 46 9 136 15 226
4 61 10 151 16 241
5 76 11 166 17 256
6 91 12 181 – –

ATEN Master View CS1308 Specifications

General

Device Type	KVM Switch
Ports	8
Max Resolution	2048 x 1536
Video Bandwidth	350 MHz
Daisy Chain	No
Number of ports	8
Console Connections	1
Operating Temperature	0 - 50°C
Storage Temperature	-20 - 60°C
Humidity	0 - 80% RH, Non-condensing
Connectors	8 x SPHD-15 Female (Yellow)
Computer Connections	8
Console Ports	1 x SPHD-15 Female
Video Resolution	2048 x 1536
Power Consumption (DC)	5W
Dimensions (mm)	437.2 x 160 x 44 mm
Power Consumption (AC)	5W
