Appendix
51
Specifications
Function CS1308 CS1316
Computer
Connections
Direct 8 16
Max. 64 (via cascade) 256 (via cascade)
Port Selection OSD, Hotkey, Pushbutton
Connectors Console
Ports
Keyboard 1 x SPHD-15 Male
(Yellow)
Video
Mouse
KVM
Ports
Keyboard 8 x SPHD-15 Female
(Yellow)
16 x SPHD-15 Female
(Yellow)
Video
Mouse
F/W Upgrade 1 x RJ11 Female (Black)
Power 1 x DC Jack
Switches Port 8 x Pushbutton 16 x Pushbutton
F/W Upgrade 1 x Slide
LEDs On Line 8 (Orange) 16 (Orange)
Selected 8 (Green) 16 (Green)
Power 1 (Dark Green)
Emulation Keyboard / Mouse PS/2, USB
Video 2048 x 1536; DDC2B
Scan Interval 1–255 Seconds
Power Consumption DC 5.3 V; 5 W DC 5.3 V; 6.6 W
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–80% RH, Noncondensing
Physical
Properties
Housing Metal
Weight 1.89 kg 2.10 kg
Dimensions
(L x W x H)
43.30 x 16.00 x 4.40 cm
