CS1308 / CS1316 User Manual
30
F8: LOUT
Clicking the F8 field, or pressing [F8] logs you out of OSD control of the
computers, and blanks the console screen. This is different from simply
pressing [Esc] when you are at the main screen to deactivate the OSD. With
this function you must log in all over again to regain access to the OSD,
whereas with [Esc], all you have to do to reenter the OSD is tap the OSD
hotkey.
Note: 1. When you reenter the OSD after logging out, the screen stays blank
except for the OSD main screen. You must input your username and
password before you can continue.
2. If you reenter the OSD after logging out, and immediately use [Esc]
to deactivate the OSD without having selected a port from the OSD
menu, a null port message displays on the screen. The OSD hotkey
will bring up the main OSD screen.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ATEN Master View CS1308 and is the answer not in the manual?

ATEN Master View CS1308 Specifications

General IconGeneral
Device TypeKVM Switch
Ports8
Max Resolution2048 x 1536
Video Bandwidth350 MHz
Daisy ChainNo
Number of ports8
Console Connections1
Operating Temperature0 - 50°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-condensing
Connectors8 x SPHD-15 Female (Yellow)
Computer Connections8
Console Ports1 x SPHD-15 Female
Video Resolution2048 x 1536
Power Consumption (DC)5W
Dimensions (mm)437.2 x 160 x 44 mm
Power Consumption (AC)5W
