CS1308 / CS1316 User Manual
40
Sun Keyboard
The PC compatible (101/104 key) keyboard can emulate the functions of the
Sun keyboard when the control key [Ctrl] is used in conjunction with other
keys. The corresponding functions are shown in the table below.
Note: When using key combinations, press and release the first key (Ctrl),
then press and release the activation key.
PC Keyboard Sun Keyboard
[Ctrl] [T] Stop
[Ctrl] [F2] Again
[Ctrl] [F3] Props
[Ctrl] [F4] Undo
[Ctrl] [F5] Front
[Ctrl] [F6] Copy
[Ctrl] [F7] Open
[Ctrl] [F8] Paste
[Ctrl] [F9] Find
[Ctrl] [F10] Cut
[Ctrl] [1]
[Ctrl] [2]
[Ctrl] [3]
[Ctrl] [4]
[Ctrl] [H] Help
Compose
-
+

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ATEN Master View CS1308 and is the answer not in the manual?

ATEN Master View CS1308 Specifications

General IconGeneral
Device TypeKVM Switch
Ports8
Max Resolution2048 x 1536
Video Bandwidth350 MHz
Daisy ChainNo
Number of ports8
Console Connections1
Operating Temperature0 - 50°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-condensing
Connectors8 x SPHD-15 Female (Yellow)
Computer Connections8
Console Ports1 x SPHD-15 Female
Video Resolution2048 x 1536
Power Consumption (DC)5W
Dimensions (mm)437.2 x 160 x 44 mm
Power Consumption (AC)5W
