9
1.3.1. Status bar icons (at the top of the screen)
The status bar is located at the top of the screen of the tool. The icons it contains provide
information on the status of the tool. These icons have the following meanings:
The tool is plugged into a USB port
The OBD-II module is plugged into the tool
The tool is connected to WiFi
The tool is connected to WebVT using WiFi connection
A new update is available (WiFi connection required)
Battery charge indicator
The optional Tire Tread Depth (TTD) accessory is plugged into the tool
