Display Parameter Available Selections
CARD
Installed Card
nonE - no card installed
SErl - Serial communications card installed
SC.di - Serial communications with Switch Input
rAS - Remote analog setpoint
A.Out - Auxilliary Output
ALr - Alarm
dI.AL - Switch Input with Alarm
FACt
OPtn
CArd
The 16C can support a variety of options, including serial communications. Use of most of these options
available options include:
- Three remote communications options are available for the 16C which allow interfacing
to remote devices utilizing the most common industry standards: RS232, RS422, and RS485. Parameters
are set in the SErl menu.
- this option allows you to select either of two setpoints for your process. The second
setpoint can be enabled only by an external switch or signal. Parameters are set in the rAS menu.
- this option allows the Setpoint Variable or Process Variable to be transmitted to a
remote device such as indicators, data recorders, computers, process controllers, etc. with 1 of 4 different
interfaces: 4-20 mA, 1-5 V, 0-20 mA, or 0-5 V. The output signal is scalable and multiple remote indicators
may be driven by the controller. (NOTE: current and voltage outputs cannot be used simultaneously.)
Parameters are set in the A.Out menu.
- Two alarm outputs are available; the action of these outputs follows the action of the A1 and A2
front panel LEDs. Parameters are set in the ALr menu.
- can be used to trigger use of a second setpoint, or to toggle the controller’s mode
from normal to standby, or to toggle between running and holding a ramp/soak recipe. Parameters are set
in the ALr menu.
- a transducer excitation option is available to provide power to remote
To Next Page
