Ambient Temperature 32°F to 140°F (0°C to 60°C)
Relative Humidity Tolerance 90%, Non-Condensing
Power 100 to 250 V, 50/60 Hz (Single-Phase); 100 to 250 Vdc; 24 Vac/dc
Power Consumption Less than 6 VA
Accuracy ±0.20% of Full Scale, (±0.10% Typical), ±1 Digit
Setpoint Resolution 1 Count / 0.1 Count
Repeatability ±1 Count
Temperature Stability 5 µV /°C (Maximum)
TC Cold-End Tracking 0.05°C /°C Ambient
Noise Rejection >100 dB Common Mode, >70 dB Series Mode
Process Sampling 10 Hz (100 ms)
Setpoint Limits Automatically Adjust to Selected TC/RTD
Alarms Adjustable for High/Low; Selectable Process, Deviation, or Band Alarms
Proportional Band 1 to Span of Sensor
Integral 0 to 9600 Seconds
Derivative 0 to 2400 Seconds
Cycle Time 200 ms; 1 to 120 sec
Control Hysteresis 1 to Span of Sensor
Autotune Operator Initiated from Front Panel
Manual Control Operator Initiated from Front Panel
Display Dual, 4-digit 0.36” (9.2 mm) LED display;
Process Value: Orange, Setpoint Value/Menu: Green
Numeric Range -1999 to 9999
Front-Panel Cutout 1.771” x 1.771” (45 mm x 45 mm)
Depth Behind Panel 3.937” (100 mm)
Front Panel Rating NEMA 4X
Operating Temperature 32 to 140° F (0 to 60° C)
Humidity Conditions 90% R.H. max., non-condensing
Parameter Retention Solid-state, non-volatile memory
Connections Input and output via barrier strip with locking terminals
Contacts Twin bifurcated
Thermocouple B, C, E, J, K, N, NIC, NNM, R, S, T, Platinel II, Maximum lead resistance
100 ohms for rated accuracy
RTD Platinum 2- and 3-wire, 100 ohms at 0° C, DIN curve standard (0.00385),
1000 ohms available
Linear 0-50 mV/10-50 mV, 0-5 V/1-5 V, 0-20 mA/4-20 mA, 0-100 mV, 0-10 V
B 5 A (120/240 Vac) relay, normally open, used for switching resistive loads. If
relays or solenoids are to be driven, select the “T” output. If a “B” output is
selected, order snubber network 235Z005U01.
E 0-20 mA
F 4-20 mA, full output to load with 500 ohm impedance max.
G High impedance ‘F’ (800 ohms max.)
S 20 Vdc pulsed output for solid-state relays.
T 1 A @ 120/240 Vac , solid-state relay, zero voltage-switched and optically
isolated from drive signal. Only resistive loads to 1A may be controlled
directly. Larger loads may be controlled using an external contactor.
Y 5 A (120/240 Vac) relay, but normally closed (output 2 only).
