25
Output Type Recommended Setting (seconds)
B (5A/3A) 15 to 120
E (0-20 mA) 0.2
F (4-20 mA) be set to 0.2
G (4-20 mA) be set to 0.2
S (pulsed 20 Vdc) 0.2
T (S.S. relay) 15 to 120**
Y (5A/3A) N.C. 15 to 120 (Output 2 only)
** “T” outputs directly driving non-inductive loads (small heaters) can have cycle times as low as 0.2 seconds.
Display Parameter Available Selections
01.Ac
Output 1 Action
rE - Reverse acting (heating)
dir - Direct acting (cooling).
01.cY
Output 1 Cycle Time *
1 to 120 - Use the or to set the cycle time between 1
and 120 seconds.
01.LL
Output 1 Low Limit
1 to 100 - Use the or to select the lower limit of the
output, between 1 and 100%
01.HL
Output 1 High Limit
1 to 100 - Use the or to select the high limit of the
output, between 1 and 100%.
02.Ac
Output 2 Action
re - Reverse acting (heating).
dir - Direct acting (cooling).
02.cY
Output 2 Cycle Time *
1 to 120 - Use the or to set the cycle time between 1
and 120 seconds.
02.LL
Output 2 Low Limit
1 to 100 - Use the or to select the lower limit of the
output, between 1 and 100%
012.HL
Output 2 High Limit
1 to 100 - Use the or to select the high limit of the
output, between 1 and 100%.
Display Parameter Available Selections
pb1
Proportional Band 1
1 to 120 - Use the or to set the cycle time between 1
and 120 seconds.
Pb2
Proportional Band 2
1 to 100 - Use the or to select the lower limit of the
output, between 1 and 100%
dEr
Derivative Action (Rate)
1 to 100 - Use the or to select the high limit of the
output, between 1 and 100%.
OFFS
Manual Reset
OFF - Reverse acting (heating).
Note - the Integral Action (Auto Reset) parameter only appears if OFF is selected in the OFFS - Manual Reset - parameter
Int
Integral Action (Auto
Reset)
0 to 9600 - Use the or to set the integral rate time
between 0 and 9600 seconds.
0
OutP
01.Ac
Ctrl
Pb1
As stated above, the Output Menu and the subsequent Control Menu will change, depending upon the
Output Type selected. The settings shown here indicate what is available when an Output type is set for PID
Control.
Note: These parameters are automatically set during the autotune procedure. We do not recommend
altering the value of these control parameters unless your process requires manual tuning. We do, however,
recommend returning to this screen once an autotune is complete to record the values for the proportional,
derivative and integral actions that have been determined for your process.
