32
Display Parameter Available Selections
F.S.01
Output 1 Failsafe State
0 to 100 - %age of output. Used when the controller
detects a problem with the input: open sensor, reversed
sensor, or loop break time exceeded.
F.S.02
Output 2 Failsafe State
0 to 100 - %age of output
L.br.t
Loop Break Time Off, 4-9600 sec. Specifies the length of the time during
which the input should change in response to output action
if the input is working normally. The controller will use this
loop break time as a criterion for going into failsafe state and
sending the outputs to the failsafe output percentages
HI.rd
Highest Reading n/a - The highest and lowest process values received since
the last reset. These readings are read-only values. To
reset the values to allow new highest and lowest process
values, press the or key.
LO.rd
Lowest Reading
Ld.dP
Load Default Parameters
yES This function returns all conguration parameter values to their
defaults
no
SuPr
F.S.01
You can use the supervisor menu to specify the output percentages to be used if the controller detects a
problem with the process input (failsafe values), and the length of the time period during which the input
should change in response to output action if the input and output are working normally (loop break time).
You can also use this menu to see the highest and lowest process value received by the controller since the
controller was powered up.
factory defaults, so recalibtaion of the controller .
