Athena Controls 16C Series - Parameters for Multi-Step Ramp Configuration

31
Display Parameter Available Selections
rcY.n
Recycle Number
S.SP.r - Single Setpoint Ramp
PF.rE
Power Fail Resume
OFF󰀨
on - On.
rt1
Ramp Times 1-8
1 Use the or to select the ramp time, between
1 and 9999 minutes
rE
Ramp Events 1-8*
A1on Alarm 1 On
A1of󰀨
A2on Alarm 2 On
A2oF󰀨
dIS Disabled
Sl
Soak Levels 1-8
75 Use the or to select the soak temperature at
󰀨
St
Soak Times 1-8
1 Use the or to select the soak time, between 1
and 9999 minutes
SE
Soak Events 1-8*
A1on Alarm 1 On
A1of󰀨
A2on Alarm 2 On
A2oF󰀨
dIS Disabled
* Note - For Ramp Events and Soak Events to be employed, Alarm 1 or Alarm 2 must be set for
event usage Eunt in the Alarm Menu. This will require you to go back to the Alarm Menu, once you
have activated a Multi-Step Ramp, to see and set alarm 1 and 2 action to the now visible Eunt
selection.
The following seven parameters shown in the table below are only available when  is
selected.
