30
If a ramp/soak error condition occurs, the upper display will toggle between r-S and the numeric
error code for three seconds before the recipe terminates. Possible error codes are:
02 = Recipe Empty (i.e. no non-zero ramp times)
05 = Insufficient Setpoint-Process Value Deviation
r-S
rOPt
Display Parameter Available Selections
rOPt
Recipe Option
S.SP.r - Single Setpoint Ramp
8.r.5 - Multi Step Ramp.
dIS - Disabled.
S.S.r.t
Single Setpoint Ramp
Time*
1 Use the or to select the ramp time, between
1 and 9999 minutes
Hld.b
Holdback Band
1 Use the or to select the Holdback Band,
tEr.S
Termination State
LASt - Last Setpoint
dEFt - Default Setpoint
Stby - Recipe to Stanby
* Note - this parameter is only available if single-setpoint ramp is selected.
Multi-Step Ramp
This selection will enable the programming of a recipe (make all ramp/soak recipe variables visible). Recipes can
be resumed on startup if interrupted by a power failure or initiated, held, and terminated from the front panel via
the Mode Menu or with the logic input option (initiate and held/resumed only). The recipe cannot be edited while
running
Specifies the maximum number of degrees above or below setpoint that the process can be for the segment timer
to keep going. If the process exceeds the holdback band, the timer will pause while the process settles back into
the band and then continue. If this feature is not desired, this parameter should be set to OFF.
Termination State
This parameter determines what the control will do at the completion of a recipe. Last Setpoint refers to the last
temperature specified in the ramp/soak recipe. Default Setpoint refers to the standard setpoint which was in effect
prior to recipe initiation.
Recycle Number
Specifies the number of times after the first time that the recipe is run before the program terminates.
Power Fail Resume
Setting this parameter to On will cause the control to resume a recipe which was active when a power failure
occurred. The recipe will resume at the start of the last active ramp or soak segment.
Ramp/Soak Events (1-8) (If alarms are configured as ramp/soak events.)
Ramp/Soak events occur at the beginning of their designated segment. All events are terminated once the recipe
has been completed or terminated. This can be used as an alarm when a segment is reached.
To Next Page
