Manual, F/T Sensor, Ethernet Axia

Document #9610-05-Ethernet Axia-09

Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel:+1 919.772.0115 • Fax:+1 919.772.8259 • www.ati-ia.com

Figure 5.5—Discovery Tool

NOTICE: In addition to the ATI website, ATI provides this discovery tool in a directory that is sent

totheuseruponreceiptofthesensor.Toaccessthetoolinthedirectory(9030-05-1026),open

thefolder“Utilities”,openthefolder“ATIDiscoveryTool”,andtheninstallthelenamed“setup”.
