9.2 CGI Variable: Settings (setting.cgi)
A user can specify certain global settings such as ADC rate, low-pass lter selection, and bias (refer to
Section6.4—ADCSettingsPage(setting.htm) for related information).
Table 9.1—setting.cgi Variables
Variable Name
Allowed
Values
Description Example
setadcrate
integers:
488, 976,
1953,
3906, 7812
(Hz)
Sets the ADC sampling rate. setadcrate=488
setuserlter
integers: 0
to 8
Sets the cutoff frequency (percent of the ADC sample
rate)ofthelow-passlteringasfollows:
setuserlter=0
Value Cutoff Value Cutoff
0 nolter 5 0.51%
1 11.97% 6 0.26%
2 4.66% 7 0.12%
3 2.17% 8 0.07%
4 1.04%
setbiasn
integers:
-32768 to
32767
Sets the offset value for strain gage n. For example,
setbias3=0 would zero the bias of the fourth strain
gage(Straingagesareenumeratedstartingatzero.)
setbias3=0
9.3 Thresholding CGI (moncon.cgi)
A user can dene Thresholding settings and conditions.
Table 9.2—moncon.cgi Threshold Settings
Variable Name
Allowed
Values
Description Example
setmce Integers: 0 or 1
Threshold statement processing: enable = 1 or
disable = 0
setmc=1
mcandcodes Integers: 0 or 1
Relay trigger: any condition is true = 0 or all
conditions are true = 1
mcandcodes=1
mcoating Integers: 0 or 1 Relay Behavior: momentary = 1 or latching = 0 mcoating=1
mcReset Integer: 1 Reset latch mcReset=1
mcresettime
Integer: 0 to
255
Relay momentary minimum-on time or a delay in
atenth(0.1)ofasecond:0seconds=0to25.2
seconds = 255
mcresttime=20
