gure 11 - Hydraulic unit components
Installation manual "1872 - EN" - 15 -
Alféa Extensa A.I. Heat Pump
Key:
1 - Electric box.
2 - Controller / User interface.
3 - Start/stop switch.
4 - Heating circulation pump.
5 - Heating ow.
6 - "Gas" refrigeration connection.
7 - "Liquid" refrigeration connection.
8 - Heating return.
9 - Drain valve.
10 - Safety valve.
11 - Pressure gauge.
12 - Manual bleeder valve.
13 - Expansion vessel.
14 - Condenser.
2
1
4 11 3
7
6
58
9
10
13
14
12
