FR
11
Présentation du
produit
Installation
Paramétrage /
Utilisation
Entretien,
Maintenance et
Dépannage
Garantie
Dimensions / structure 6.
Réf
MODELE
200 L
270 L
A
Evacuation des condensats
1214
1548
B
Hauteur totale
1526
1859
C
Hauteur entrée eau froide
302
302
D
Hauteur sortie eau chaude
960
1300
E
Largeur totale
621
621
F
Profondeur totale
647
647
Dimensions en mm
