The picture of the water heater in the figure above is not contractual.
Observe the minimum clearance specified to avoid air recirculating.
The product must not be in contact with the walls to avoid transmission of vibrations.
To prevent damages to the product and reduce its performance, air inlets and outlets must not be
blocked, covered or obstructed.
150mm
mini
710mm
mini
400mm
mini
600mm
mini
120mm
mini
Example of
installation
without
cladding
Minimum total
height from floor
to ceiling
200 L : 1,68 m
270 L : 2,01 m
>20m3
Without the volume of
bulky items
Room temperature
between 5 et 35°C, without
water heater operation.
600 mm
mini
300 mm
mini
300 mm
mini
900 mm
mini
