3.4 Scroll keys
Control panel
The keys (1) allow the operator to scroll through the display.
As long as a downwards pointing arrow is shown at the far right position of the display, the scroll key with
the same symbol can be used to see the next item.
As long as an upwards pointing arrow is shown at the far right position of the display, the scroll key with
the same symbol can be used to see the previous item.
3.5 Emergency stop button
Control panel
In the event of an emergency, press button (S3) to stop the compressor immediately.
Before restarting, unlock the emergency stop button by pulling it out and push the reset button on the
Elektronikon.
Warning: use S3 only in case of emergency. Use the stop button for normal stopping.
Before starting any maintenance or repairs, wait until the compressor has stopped. Close
the air outlet valve, depressurize the compressor and switch off the voltage to the
compressor if necessary. See section Problem solving for full details. Always apply all
relevant Safety precautions.
3.6 Control programs
Description
In order to facilitate programming and controlling, menu-driven control programs have been implemented
in the regulator.
Instruction book
28 API603130
