9 Technical data
9.1 Readings on display
Elektronikon II regulator
Important
The readings mentioned below are valid under the reference conditions (see section
Reference conditions and limitations).
Reference Reading
Air outlet pressure Fluctuates between programmed unloading and loading pressures.
Compressor element
outlet temperature
For air-cooled units: approx. 60 ˚C (108 ˚F) above cooling air inlet temperature
Dew point temperature See section Compressor data.
Pressure difference
over oil separator
Below 1 bar (14.5 psi).
Instruction book
API603130 85
