‘Previous Timer’
‘Level’ A B
‘hrs’ 4008
.
F1 F2 F3
• The screen shows that service plans A and B were carried out at 4008 running hours.
• Stop the compressor, switch off the voltage and carry out the service operations related to plans A, B
and C; see section Preventive maintenance schedule.
• Switch on the voltage and scroll to the ‘Next Timer’ service screen.
• Press the ‘Rset’ button (F3). Confirm the question for resetting.
The ‘Rset’ button only appears when the ‘Next Timer’ level is almost reached.
After pressing the arrow down key in the ‘Service Timer’ screen, the ‘Life Time’ hours are
shown, i.e. the number of hours elapsed since initial programming ex-factory. This timer is
not taken into account.
3.22 Saved data menu
Control panel
Function
To call up some compressor data saved by the regulator. These data are:
• Last shut-down data
• Last emergency stop data
Procedure
Starting from the Main screen:
• Press the key ‘Menu’ (F1).
• Press the arrow down key (1) until the option ‘Saved Data’ is followed by a horizontal arrow.
• Press the tabulator key (2) to activate the menu.
• The list of last shut-down and emergency stop cases is shown.
• Scroll through the items to select the desired shut-down or emergency stop item.
• Press tabulator key (2) to find the date, time and other data reflecting the status of the compressor
when the last shut-down occurred.
Instruction book
50 API603130
