13 Cooling air grating, dryer
Safety
The operator must apply all relevant safety precautions, including those mentioned in this
book.
Outdoor/altitude operation
Fix speed compressors can be sold with option "rain protection". With this option, this compressor can be
installed outside under a shelter, in frost free conditions. If frost might occur, the appropriate measures
should be taken to avoid damage to the machine and its ancillary equipment. In this case, and also if
operating above 1000 m (3300 ft), consult Atlas Copco.
Moving/lifting
The compressor can be moved by a lift truck using the slots in the frame. Take care not to damage the
bodywork during lifting or transport. Before lifting, reinstall the transport securing bolts. Make sure that
the forks protrude from the other side of the frame. The compressor can also be lifted after inserting beams
in the slots. Make sure that the beams cannot slide and that they protrude from the frame equally. The
chains must be held parallel to the bodywork by chain spreaders in order not to damage the compressor.
The lifting equipment must be placed in such a way that the compressor is lifted perpendicularly. Lift
gently and avoid twisting.
In case of units equipped with the Lifting Device Option, it is not allowed to lift the
compressor if the canopy parts or lifting supports are not completely installed. When the
compressor is being lifted, it is also forbidden to come under the load or to perform
maintenance activities to it.
4.3 Electrical connections
Important remark
To preserve the protection degree of the electric cubicle and to protect its components from
dust from the environment, it is mandatory to use a proper cable gland when connecting the
supply cable to the compressor.
Instruction book
API603130 57
