Electrical connections
Reference Designation
(1) Customer’s installation
(2) 220/230 V: K21, K23 size 10 with 6 fuses type 1
(3) > 230 V: K21, K23 smaller than size 10 with 3 fuses type 1
(4) Option dryer
(5) All voltages except: 440-460 V 60 Hz
(6) Star connection: all other voltages
Instruction book
58 API603130
