‘Clock Function’
‘Not Activated’
.
‘Menu’ ‘Mod.’ ‘Del.’
F1 F2 F3
• Press the tabulator key (2), the following screen appears:
‘Monday’
‘Tuesday’
‘Wednesday’
‘Menu’ ‘Del.’
F1 F2 F3
• Scroll through the display until ‘Saturday’ is followed by a horizontal arrow. Press the tabulator key
(2). If necessary, scroll through the commands until the command to be modified is followed by a
horizontal arrow. Press the key ‘Mod.’, the first two digits of the command start flashing. Modify as
required using the scroll keys, i.e. in the example above change 18 to 17 using the arrow up key (1).
• If necessary, press the tabulator key (2) to go to the next field to be modified, the minutes indication
and the start/stop/pressure band indication.
• Press the key ‘Prog’ to program the new command or the key ‘Canc’ to quit without reprogramming.
Adding a command at the end of an existing list
• Starting from the Main screen, press the key ‘Menu’ (F1), press the arrow down key until the option
‘Modify Params’ is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Use the arrow down key (1) to scroll until the option ‘Clock Function’ is followed by a horizontal
arrow. Press the tabulator key, the following screen appears:
‘Clock Function’
‘Not Activated’
.
‘Menu’ ‘Mod.’ ‘Del.’
F1 F2 F3
Suppose the command to stop the compressor at 18:00 must be added to the list of Monday.
• Press the tabulator key (2), the following screen appears:
‘Monday’
‘Tuesday’
‘Wednesday’
‘Menu’ ‘Del.’
F1 F2 F3
Instruction book
API603130 45
