Page #121 background imageLoading...
Page #121 background image
9.2 Electric cable size and fuses
Important
The voltage on the compressor terminals must not deviate more than 10% of the
nominal voltage.
It is however highly recommended to keep the voltage drop over the supply cables
at nominal current below 5% of the nominal voltage (IEC 60204-1).
If cables are grouped together with other power cables, it may be necessary to use
cables of a larger size than those calculated for the standard operating conditions.
Use the original cable entry. See section Dimension drawings.
To preserve the IP protection degree of the electric cubicle and to protect its
components from dust from the environment, it is mandatory to use a proper
cable gland when connecting the supply cable to the compressor.
Local regulations remain applicable if they are stricter than the values proposed
below.
Caution:
Always double-check the fuse size versus the calculated cable size. If
required, reduce fuse size or enlarge cable size.
Cable length should not exceed the maximum length according to IEC60204
table 10.
Leakage breaker (optional)
If the installation requires a leakage breaker, always use an all current sensitive leakage breaker, RCM or
RCD Type B (according to IEC/EN 60755) with a sufficient trip level.
Currents and fuses
Compressor type I
max
(1) Max
fuse (1)
I
max
(2) Max fuse
(2)
GA 7 VSD+ IEC 50 Hz 200 V 36.8 A 40 A 39.9 A 50 A
GA 7 VSD+ IEC 50 Hz 230 V 32.1 A 40 A 35.2 A 50 A
GA 7 VSD+ IEC 50 Hz 400 V + N - - 20.0 A 25 A
GA 7 VSD+ IEC 50 Hz 400 V 18.4 A 20 A 20.0 A 25 A
GA 7 VSD+ IEC 50 Hz 500 V 14.7 A 20 A 16.0 A 20 A
GA 7 VSD+ IEC 60 Hz 200 V 36.8 A 40 A 39.9 A 50 A
GA 7 VSD+ IEC 60 Hz 230 V 32.1 A 40 A 35.2 A 50 A
GA 7 VSD+ IEC 60 Hz 380 V 19.5 A 20 A 21.0 A 25 A
GA 7 VSD+ IEC 60 Hz 460 V 16.1 A 20 A 17.6 A 25 A
GA 7 VSD+ UL/cUL 60 Hz 200 V 36.8 A 40 A 39.9 A 50 A
GA 7 VSD+ UL/cUL 60 Hz 230 V 32.1 A 40 A 35.2 A 50 A
GA 7 VSD+ UL/cUL 60 Hz 460 V 16.1 A 20 A 17.6 A 25 A
GA 7 VSD+ UL/cUL 60 Hz 575 V 12.8 A 20 A 14.1 A 20 A
Compressor type I
max
(1) Max
fuse (1)
I
max
(2) Max fuse
(2)
GA 11 VSD+ IEC 50 Hz 200 V 48.8 A 60 A 51.9 A 60 A
Instruction book
2920 7109 23 119
