3.15 Week timer menu
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Menu icon, Week timer
Function
• To program time-based start/stop commands for the compressor
• To program time-based change-over commands for the net pressure band
• Four different week schemes can be programmed.
• A week cycle can be programmed, a week cycle is a sequence of 10 weeks. For each week in the
cycle, one of the four programmed week schemes can be chosen.
Important remark:
In the Elektronikon you can select different timers on one day.(up to 8 actions). It is
however not possible to program 2 actions at the same time. The solution: leave at least
1 minute in between 2 actions.
Example: Start Compressor: 5.00 AM, Pressure Setpoint 2: 5.01 AM (or later).
Procedure
Starting from the Main screen (see Main screen),
• Move the cursor to the action button Menu and press the Enter key. Use the Scroll buttons to select
the Timer icon.
Instruction book
2920 7109 23 51
