Text on figure
(1) Menu
(2) Week Timer
• Press the Enter key on the controller. Following screen appears:
(1) Week Timer
(2) Week Action Schemes
(3) Week Cycle
(4) Status
(5) Week Timer Inactive
(6) Remaining Running Time
The first item in this list is highlighted in red. Select the item requested and press the Enter key on the
controller to modify.
Programming week schemes
• Select Week action schemes and press Enter. A new window opens. The first item in the list is
highlighted in red. Press the Enter key on the controller to modify Week Action Scheme 1.
Instruction book
52 2920 7109 23
