3.5 Calling up menus
Control panel
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Description
When the voltage is switched on, the main screen is shown automatically (see section Main screen):
Typical Main screen (2 value lines)
• To go to the Menu screen, select <Menu> (3), using the Scroll keys.
• Press the Enter key to select the menu. Following screen appears:
