9.4 Compressor data
Reference conditions
All data specified below apply under reference conditions, see section Reference
conditions and limitations.
Common compressor data
Unit
Number of compression stages 1
Temperature of the air leaving the outlet valve (approx.), Workplace ˚C 30
Temperature of the air leaving the outlet valve (approx.), Workplace ˚F 86
Temperature of the air leaving the outlet valve (approx.), Workplace Full-
Feature
˚C 30
Temperature of the air leaving the outlet valve (approx.), Workplace Full-
Feature
˚F 86
Refrigerant type, Workplace Full-Feature R134a
GA 7 VSD+
Normal effective working pressure bar(e) 5.5 7 9.5 12.5
Normal effective working pressure psig 80 102 138 181
Maximum effective working pressure,
Workplace
bar(e) 13 13 13 13
Maximum effective working pressure,
Workplace
psig 189 189 189 189
Maximum effective working pressure,
Workplace Full-Feature
bar(e) 12.75 12.75 12.75 12.75
Maximum effective working pressure,
Workplace Full-Feature
psig 185 185 185 185
Maximum motor shaft speed rpm 5250 5250 4500 3750
Minimum motor shaft speed rpm 1900 1900 1900 2100
Nominal motor power kW 7.5
Nominal motor power hp 10
Total amount of refrigerant, Workplace Full-Feature kg 0.4
Total amount of refrigerant, Workplace Full-Feature lb 0.88
Oil capacity l 6.5
Oil capacity US gal 1.72
Oil capacity Imp. gal 1.43
Oil capacity cu. ft. 0.23
Sound pressure level (according to ISO 2151 (2004)) dB(A) 62
Instruction book
2920 7109 23 125
