This causes the air to cool further close to the evaporating temperature of the refrigerant. More water in the
air condenses.
The cold air flows through the separator (3) where all the condensate gets out of the air.
The condensate is automatically drained through the outlet (4).
The outgoing, cold, dried air flows through the heat exchanger (1) where it is warmed up by the incoming
compressed air.
Refrigerant circuit
Refrigeration dryers of ID type contain high efficient refrigerant R134a of the HFC group.
The refrigerant compressor (5) delivers hot, high-pressure refrigerant gas which flows through the
refrigerant condenser (6).
Most of the refrigerant condenses.
The liquid refrigerant flows through the liquid refrigerant dryer/filter (7) to the capillary tube (8).
The refrigerant leaves the capillary tube at about evaporating pressure.
The refrigerant enters the evaporator (2) where it gets heat from the compressed air by further evaporation
at about constant pressure.
The heated refrigerant leaves the evaporator and gets into the compressor (5) through a liquid separator
(12).
A bypass valve (9) regulates the refrigerant flow.
The fan (10) blows cool air over the refrigerant condenser (6)
The switch (11) sets the fan (10) to on or off, depending on the pressure degree of the condensate.
