- 25 -
4 Operating instructions
4.1 Before starting
With the generator standing level, check the
engine oil level and top up if necessary. The oil
level must be near to, but not exceed the high mark
on the engine oil level dipstick.
Check the coolant level in the expansion tank of
the engine cooling system. The coolant level must
be near to the FULL mark. Add coolant if
necessary.
Drain any water and sediment from the fuel pre-
filter. Check the fuel level and top up if necessary.
It is recommended to fill the tank after the day’s
operation to prevent water vapour in a nearly
empty tank from condensing.
Drain leaking fluid from the frame.
Check the vacuum indicator of the air filter. If the
red part shows completely, replace the filter
element.
Press the dust evacuator of the air filter to remove
dust.
Check the generator for leakage, tightness of wire
terminals, etc. Correct if necessary.
Check that circuit breaker Q1 is switched off.
Check that fuse F10 has not tripped and that the
emergency stop is in the OUT position.
Check that the load is switched off.
Check that the earth fault protection (N13) has not
tripped (reset if necessary).
4.2 Operating and setting
Qc1103™
4.2.1 Starting
Switch on the battery switch, if applicable.
Turn starter switch S20 to position I (ON) to
power up the Qc1103™ controller.
Switch off circuit breaker Q1.
Select the desired operating mode on the
Qc1103™ controller (see chapter “Running
modes” on page 33 for the possible selections).
To start-up the generator in MANUAL mode:
•Press the MAN push button on the Qc1103™
controller to activate MANUAL mode.
•Use the START button to start-up the
generator.
The unit will start.
In cold conditions the unit might not start from
the first attempt. The controller will make 3
start attempts.
Allow the generator to start-up till voltage and
frequency are OK (
Hz/V ok lights up).
Switch on circuit breaker Q1.
To start-up the generator in AUTO mode:
•Press the AUTO push button on the Qc1103
controller to activate AUTO mode.
Switch on circuit breaker Q1.
In your own interest, always strictly
observe all relevant safety
instructions.
Do not operate the generator in
excess of the limitations mentioned
in the Technical Specifications.
Local rules concerning the setting
up of low voltage power installations
(below 1000 V) must be respected
when connecting site distribution
panels, switch gear or loads to the
generator.
At each start-up and at any time a
new load is connected, the earthing
and protections (GB trip and earth
leakage relay) of the generator must
be verified. Earthing must be done
either by the earthing rod or, if
available, by an existing, suitable
earthing installation. The protective
system against excessive contact
voltage is not effective unless a
suitable earthing is made.
!
