Atlas Copco QAS 60 Pd S3A ESF User Manual

- 88 -
10.3 Critical bolt connections
Applications
Screw / Bolt / Nut
Type Material Torque (Nm)
Lifting beam to frame M12 8.8 85
Horizontal lifting beam to vertical lifting beam M12 8.8 85
Coupling housing alternator to flywheel housing engine M10 8.8 46
Rotor disk alternator to flywheel engine 3/8" UNC 12.9 40
Engine to engine support (included with engine) - - -
Engine support to vibration damper engine M16 8.8 205
Vibration damper engine to frame M12 8.8 85
Alternator support to vibration damper alternator M12 8.8 85
Vibration damper alternator to frame M12 8.8 85
Wheel to axle M14 8.8 137
Axle to undercarriage frame M12 8.8 88
Towbar to undercarriage frame M14 8.8 137
Towing eye to towbar M12 8.8 85
Undercarriage frame to box B frame M16 8.8 211
Standard torques
M8 8.8 24.3
M10 8.8 48.2
M12 8.8 83
M16 8.8 205
UNC 1/4-20 8.8 11
UNC 5/16-18 8.8 22
UNC 3/8-15 8.8 40
UNC 7/16-14 8.8 71
