Installation Steps
14
PV
-12P
E. Install hydraulic cylinders
Connect the extended straight
fi
tting and 90°
fi
tting. Install the cylinders
through the carriages
.
Fig. 16
Use T
e
fl
on tape to seal pipe threads.
Do not use te
fl
on tape on hydr
aulic hose ends.
P
ower side column
Off side column
Fitting towards the
hole of the column
13
15
Table of Contents
