Installation Steps
24
PV
-12P
L. Install cables
1.
High setting cable connection
, suitable for ceiling height over 4500mm
(177 -1/8”).
1.1 T
ak
e out the carriages’ plastic covers, cable passes through from the
bottom of the carriages and pulled out from the openings of the carriages,
then screw the two cable nuts.
Fig. 27
Cable
connecting
direction
Cable
connecting
direction
23
25
