Parts List For Model PV-12PX 43
PV-12P
Parts List For Model PV-12PX
Item Part# Description Qty. Note
1 217001B Power side column 1
203 209002A Power unit 1
3 209003 Bolt 4
4 209033 Lock washer 4
5 209005 Self locking Nut 4
6 217003 Power side lock cover 1
7 217004 Main cam lock 1
8 217069 Hex Bolt 34
9 206006 Washer 35
10 206023 Self locking nut 34
11 420018 Self locking nut 8
12 217013 Hex Bolt 8
13 420045 Washer 30
14 61K074 Protective ring 2
15 217015B Right overhead bar 1
16 217016B Left overhead bar 1
17 420044 Pin stop 2
18 209149 Washer 4
19 420138 Socket Bolt 4
20 217019 Top pulley 4
21 217020 Bronze bush for pulley 6
22 217021 Top pulley spacer 4
23 217022 Pin 2
24 217023 Pin spacer 2
25 217024 Hose support 2
26 206009 Plastic small pulley 3
27 209056 Self locking nut 3
To Next Page
