Parts List For Model PV-12PX 44
PV-12P
Item Part# Description Qty. Note
28 209046 Hex Bolt 3
29 217026 Safety cable bracket 2
30 217027B Extension column 2
31 217028 Offside lock cover 1
32 217034B Offside column 1
33 209051B Adapter 1.5” 4
34 209052B Adapter 2.5” 4
35 209053B Adapter 5” 4
36 207045 Anchor bolt 12
37 620065 Shim 10
38 217114A Rubber pad assy. 4
38A 420138 Socket bolt 4
38B 209134 Rubber Pad 4
38C 680030B Rubber Pad frame 4
39 217036 Bottom pulley 2
40 217037 Bottom pin 2
41 209038 Hex Bolt 6
42 217047B Arm pin 4
42A 520023
Snap ring
4
43 209039
Lock washer
18
44 209022
Washer
18
45 206049
Moon gear
4
46 217052C Lifting arm 4
46A 217120 Outer arm 4
46B 217121A Inner arm 4
47 206048 Socket bolt 12
48 206032 Snap clip 4
49 640109 Washer 8
50 206036 Roll pin 4
51 217044 Arm lock 4
