Parts List For Model PV-12PX 45
PV-12P
Item Part# Description Qty. Note
52 217045A Spring 4
53 217046C Left arm lock bar 2
54 217046B Right arm lock bar 2
55 209019 Flat head screw 12
56 217053 Rubber pad 2
57 209009 Cup head bolt 28
58 217054 Carriage plastic cover 2
59 217196 Carriage 2
60 217188 Slider block 16
61 217056A Cylinder 2
62 217173 Wire cable 1
63 206025A Foam Cushion 1
64 206129 Limit bar 1
65 201005 Split Pin 2
66 206025C Limit bar link 2
67 206013 Limit switch 1
68 206011 Cup head bolt 2
69 206042 Limit bar bracket 2
70 420026 Lock washer 1
71 206023A Hex Nut 1
72 217005 Plastic ball 1
73 217006 Lock handle 1
74 217007 Large spacer 2
75 217030 Main spring 2
76 217009 Main lock 2
77 217010 Hex Bolt 1
78 217011 Hex Nut 1
79 217012 Small spacer 2
80 217050 Main lock pin 2
81 217051 Socket bolt 2
To Next Page
