Parts List For Model PV-12PX 46
PV-12P
Item Part# Description Qty. Note
82 217066 Hex Bolt 2
83 217008 Torsion spring 1
84 217031 Cam lock 1
85 217033 Self locking nut 1
86 217032 Cable lock hold 1
87 217029 Small pulley bracket 1
88 217222 Oil hose 2
89 209060 90 for power unit 1
90 217223 Oil hose 1
91 207035 Extend straight tting 2
91A 217221 straight tting 2
92 420097 90 Fitting 2
93 217191 Retainer 12
94 420029 Cable nut washer 4
95 209066 Cable nut 8
96 217063B Cable with nut 2
97 217064B Safety cable 1
98 217068 Column connecting plate 2
101 201090 Shim 10
102 211016 T- tting 1
103 217501B Parts box 1
For optional short cable and hose
99 217112 Short cable 2
Parts For Hydraulic Cylinder
61-1 209069 O-Ring 2
61-2 209070 Bleeding Plug 2
61-3 209071 Support Ring 2
61-4 209072 Y-Ring 2
61-5 209073 O-Ring 2
61-6 209074 Piston 2
