Installation Steps 27
PV-12P
3. Special low setting cable connection, suitable for ceiling height less than
4200mm (165 3/8”), for this setting use with the optional short cable.
Fig. 30
Special Low
Setting
96
99
94
Cable 2
Cable 1
Cable 2
