156

7679H–CAN–08/08

AT90CAN32/64/128

Figure 14-11. Timer/Counter Timing Diagram, Setting of OCF2A, with Prescaler (f

clk_I/O

/8)

OCFnx

OCRnx

TCNTn

OCRnx Value

OCRnx - 1 OCRnx OCRnx + 1 OCRnx + 2

clk

I/O

clk

(clk

I/O

/8)
