Fig. 38. Removing the heating coil
Fig. 37. Mirror quick heater
Grid
6.4 Changing the heating coil of the
mirror quick-heater
) Grid and sleeve might get very hot. Allow them to cool
down before changing the heating coil!
• Switcho󰀨themainswitchoftheENTunit(
1
,g.1,page
8).
• Remove grid (
1
,g.37).
• Remove the heating coil (
1
,g.38)fromtheplug
connections.
• Insert a new heating coil and make sure that the three
heating helices come into contact only with their ends.
• Fix the grid again and set main switch to ON.
