Atmos C 21 - 9.0 Technical data

36
9.0 Technical data
Voltage 230 V~ ± 10 %; 50/60 Hz
Special voltage (optional):
115 V~ ± 10 %; 50/60 Hz
127 V~ ± 10 %; 50/60 Hz
Current consumption ATMOS C 21
Max. 2.6 A (230 V~)
Max. 5.2 A (115/127 V~)
ATMOS C 31
Max. 5.0 A (230 V~)
Max. 10.0 A (115/127 V~)
Power consumption ATMOS C 21
Max. 600 W
ATMOS C 31
Max. 1150 VA
Fuses ATMOS C 21
T 3.15 A / 250 V (for 230 V~, 50/60 Hz)
T 6.3 A / 250 V (for 110 V~, 127 V~, 50/60 Hz)
ATMOS C 31
T 6.3 A / 250 V (for 230 V~, 50/60 Hz)
T 12 A / 250 V (for 110 V~, 127 V~, 50/60 Hz)
Suction system 40 l Freeow:40l/min±10%
Vacuum: 90 % from ambient pressure (variable)
Secretion canister, 1,25 l TPX
Suction system 55 l
(optional)
Freeow:55l/min±10%
Vacuum: 97 % from ambient pressure (variable)
Secretion canister, 1,25 l TPX
Compressed-air system Freeow:21l/min±10%
Pressure 2200 hPa (variable)
Cold light source for light
guide connection
Illuminance: min. 195 kLux (in 5 cm distance of a 4.7 mm high-performance light guide)
In 10 steps from 10-100 % variable
Colour temperature: 5.500 K ± 10 %
Power supply for ATMOS
LS21 LED and ATMOS HL
21 LED
Electricity: 700 mA ± 5 %
In 10 steps from 10-100% variable
Compressed air-ear
irrigation system
Temperature: 37°C ± 2°C
Filling quantity: 2 x 250 ml
Ear irrigation system Temperature: 37 °C ± 2 °C
Flow: ca. 450 ml/min
Filling quantity: 5.0 l
Endoscope heating Temperature: ca. 40 °C
Operation time Continuous operation
Protective earth conductor
resistance
Max.0,1Ω
Earth leakage current Max. 0.5 mA
Enclosure leakage current Max. 0.1 mA
Patient leakage current Max. 0.1 mA
