3.1.1 Service compartment
Fig. 2. ATMOS C 21 / C 31 Service compartment
Hose for automatic secretion canister evacuation (optional)
Connecting nipple with hose to the vacuum pump
Secretion hose
Connecting electrodes for automatic secretion canister evacuation (optional)
Attachment for secretion hose
Secretion canister
Lid(variantwithbacteriallterplate)
3.0 Setting up and starting up
1 2 3 4 5
6
7
1
2
3
4
5
6
7
