Atmos C 21 - Page 42

42
Immunity Test IEC 60601- Test Level Compliance Level Electromagnetic Environment -
Guidance
Voltage Dips / Dropout
IEC 61000-4-11
< 5 % U
T
(> 95 % Dip of the U
T
)
for 0,5 Cycles
40 % U
T
60% Dip of the U
T
)
for 5 Cycles
70% U
T
(30 % Dip of the U
T
)
for 25 Cycles
< 5 % U
T
(>95 % Dip of the U
T
)
for 5 s
< 5 % U
T
(> 95 % Dip of the U
T
)
for 0,5 Cycles
40 % U
T
60% Dip of the U
T
)
for 5 Cycles
70% U
T
(30 % Dip of the U
T
)
for 25 Cycles
< 5 % U
T
(>95 % Dip of the U
T
)
for 5 s
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the ATMOS C 21 / C 31
demands continued function even in case
of interruptions of the energy supply, it is
recommended to supply the ATMOS C 21 /
C 31 from an uninterruptible current supply
or a battery.
NOTE U
T
is the mains alternating current prior to application of the test levels.
12.3 Guidelines and Manufacturer´s Declaration - Immunity
TheATMOSC21/C31isintendedforuseintheelectromagneticenvironmentspeciedbelow.Thecustomeroruserofthe
ATMOS C 21 / C 31 should ensure that it is used in such an environment.
Immunity Test
IEC 60601- Test
Level
Compliance Level Electromagnetic Environment - Guidance
Conducted RF IEC
61000-4-6
3 V
e󰀨
150 kHz to 80 MHz
3 V
Portable and mobile communications equipment
should be separated from the ATMOS C 21 / C
31 incl. the cables by no less than the distances
calculated/listed below.
Recommended distances:
d=(3.5/V1)*√(P)
d=(3.5/E1)*√(P)80-800MHz
d=(7/E1)*√(P)0.8-2.5GHz
where„P“isthemax.powerinwatts(W)andDisthe
recommended separation distance in meters (m).
Fieldstrengthsfromxedtransmitters,asdetermined
by an electromagnetic site (a) survey, should be less
than the compliance level (b).
Interference may occur in the vicinity of equipment
containing following symbol:
Radiated RF IEC
61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m
12.0 Notes on EMC
