Atomos Ninja-2 User Manual

Atomos Ninja-2 – User Manual Edition 1: November 2012 8
Tur ning ON pow er to th e N inja-2
The start button is located on the right hand side of the unit (as you
look at the screen). Momentarily press the circular button on the right
side of the Ninja-2 as you look at the screen to power up the unit. After
a couple of seconds you will see the Atomos logo, and then the Ninja-2
Home Screen.
Tur ning OFF po wer to t he Ninja-2
To tur n t he uni t off, touch PHQX on the home screen, and then press
the red 3RZHU  RҬ icon for 4 seconds the icon will go white when
touched to indicate activation of the button. The unit will then power off.
You ca n als o d o a f orce d p ow er dow n by depressing the on/off button
for four seconds.
Four seconds can seem like a long time! We’ve made it this way to
make absolutely certain that the Ninja-2 can’t be turned off accidentally.
HDMI in: The video input to the Ninja-2 is HDMI. This is the signal that
is recorded to the Ninja-2’s storage media.
HDMI out: This is for connection to an external monitor or other device
with an HDMI input.
Audio: The Ninja-2 can record 2 channels of digital audio embedded in
the HDMI signal. There is a 3.5mm Stereo Line-in socket for recording
audio in sync with incoming video. Depending on your set-up, you may
find that this gives you better results than the microphone on the camera.
You ca n swi tch b etw een A na l ogu e A ud io Lin e In and HD MI as yo ur au dio
sources in the user interface, where you can also adjust the analogue
audio input level.
There is also a 3.5mm output that doubles as a Line Out or Headphone
Out, which has it’s own independent level control in the user interface.
5. Ninja-2 connections
ON
+ forced
power
down
Turn ing OF F pow er via touc hsc reen (p referred)
SRZHURҬ
PHQX
Master Caddy Slot
Simple, locking HDD/ SSD
system. Less than ½5 per
HDD/SSD case, this is a safe
practical solution to video
media management
HDMI In
HDMI out
>
Record loop through
>
PLAYOUT
Stereo line in
Stereo line out/Headphone
4. Connecting the Ninja-2 and powering up

Atomos Ninja-2 Specifications

General

Display resolution	800 x 480 pixels
Aspect ratio	4:3, 16:9
Product color	Black
Playback resolutions supported	HD 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p25, \\r 1080p24, 1080p23.98, 1080p30(60i), 1080p25(50i), \\r 1080p24(60i), 1080p23.98(60i), 720p60, 720p59.94, \\r 20p50, SD 486i59.94, 576i50
HDMI ports quantity	4
HDD size	2.5 \
HDD interface	Serial ATA
Maximum HDD capacity	1000 GB
Number of HDDs supported	1
Power consumption (max)	6.8 W
Power consumption (typical)	3.3 W

Weight and Dimensions

Weight	670 g
Dimensions (WxDxH)	115 x 87 x 41 mm
