We try to provide you with as complete a package as possible: you don’t
have to add anything except 2.5” storage media (you can buy additional
packs of empty Master Disk Caddies from your Atomos Reseller) and
some cables to suit your set-up, like HDMI cables and tripod screws. All
other parts necessary to use the Ninja-2 are included in the carry case.
Here’s the complete list
• Ninja-2 body (the itself, with touchscreen,
inputs and slot for Ninja-2 disk caddies)
• 2 x empty Master Disk Caddies + 8 screws for fixing disks
• Master Caddy Docking Station with
a. USB 2 & 3 Cable
(Under Ninja-2 body)
b. Firewire
®
Cable (Under dock)
c. USB 2.0 power cable for extra USB power when required (Under dock)
• Battery Charger with Power Supply Unit located underneath
• 2 x Atomos 7.4 V 2600mAh Batteries
• Ninja-2 Carry Case
• Ninja-2 Quick Start Guide (not pictured)
Atomos does not sell storage and your package will not contain any
spinning disks or SSDs. You can buy these locally to keep running
costs as low as possible.
We recommend drives, please refer to Part 16 (Technical Specifications)
of this manual. For the most up-to-date information please visit:
http://atomos.activehosted.com/kb/article/compatibility/
what-drives-do-we-recommend
1. What’s included
Contents may differ from those shown here.

Atomos Ninja-2 Specifications

General

Display resolution	800 x 480 pixels
Aspect ratio	4:3, 16:9
Product color	Black
Playback resolutions supported	HD 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p25, \\r 1080p24, 1080p23.98, 1080p30(60i), 1080p25(50i), \\r 1080p24(60i), 1080p23.98(60i), 720p60, 720p59.94, \\r 20p50, SD 486i59.94, 576i50
HDMI ports quantity	4
HDD size	2.5 \
HDD interface	Serial ATA
Maximum HDD capacity	1000 GB
Number of HDDs supported	1
Power consumption (max)	6.8 W
Power consumption (typical)	3.3 W

Weight and Dimensions

Weight	670 g
Dimensions (WxDxH)	115 x 87 x 41 mm
