Atomos SHINOBI User Manual

8. Technical Specifications
Weight and Dimensions
Without batteries
196g / 7oz.
Dimensions (W x H x D mm)
151 x 91.5 x 31.5mm
Construction
Polycarbonate ABS
Mounting points
1/4”-20 screw mount. 1x top and 1x bottom
Power
Operating power
4-7W
Compatible batteries
NP-Fseriesandsupportingaccessories.AtomXorother.
Input voltage (battery)
6.2V to 16.8V
Battery time* (based on 7.4V)
Standby
2600mAh - 3hrs
5200mAh - 6hrs
7800mAh - 12hrs
Monitor
2600mAh - 1.5hrs
5200mAh - 3hrs
7800mAh - 6hrs
DC In
via Battery Eliminator
Touchscreen
Size
5.2"
Resolution / PPI
1920 x 1080 / 427ppi
Aspect ratio
16:9 native
Color Gamut
Rec709 HDTV
Bit depth
10-bit(8+2FRC)
Brightness
1000nit(+/-10%)
Look up table (LUT) support
3DLUT(.cubeformat).Extendedsupportplanned
Anamorphic de-squeeze
2x, 1.5x, 1.33x
Technology
IPSpanel(capacitivetouch),
calibration to Rec.709 with optional calibration unit
AtomHDR
Yes
HDR Monitoring (Gamma)
Sony SLog / SLog2 / SLog3
Canon CLog / CLog2 / Clog3
ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 /
LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /
LogCEI1000 / LogCEI1280 / LogCEI1600
Panasonic Vlog
JVC JLog1
RED Log3G10 / RED LogFilm
FujiFilm F-log
Nikon N-Log
PQ10k
HLG
HDR Monitoring (Gamut)
Sony SGamut / SGamut3 / SGamut3.cine
Canon Cinema / DCI P3 / DCI P3+
Panasonic V Gamut
Arri Alexa Wide Gamut
Rec709 / BT.2020
JVC
RED WideGamut / RED DragonColor / DragonColor2 /
RED Color2 / RED Color3 / RED Color4 /
Screen Mirror/Flip
HorizontalFlip(Selemode),VerticalFlip
Landscape/Portait mode planned
†
Anti-reective
SpecialARcoatingandAnti-ngerprinttechnology
Video Input
HDMI
1xHDMI(1.4)
Signal
Up to Uncompressed true 10-bit or 8-bit 422
(cameradependent)
Supported Formats (Video Input)
4K 4096 x2160
23.98p, 24p, 25p, 29.97p
UHD 3840 x 2160
23.98p, 24p, 25p, 29.97p
HD 1920 x 1080
23.98p, 24p, 25p, 29.97p, 50p, 59.94p
HD 1280 x 720
50p, 59.94p
Audio In (48kHz)
HDMI
2ch. 24-bit 48kHz
Audio Out
Headphone out
3.5mm Headphone out 2ch.
SD Card Slot
Full size SD Card slot
SD Card Slot allows LUTs to be loaded to the unit and is also
usedwhenupdatingAtomOSrmware
AtomOS
Monitoring Features
Luma Waveform, RGB parade, RGB Overlay, Vectorscope,
Vectorscope Zoom, Histogram, RGB Histogram, Analysis
view(Multi-toolscopes:Waveform,Histogram,Vectorscope),
Focus Peaking, Zebra, False Color, Blue Only Exposure,
Zoom(1:1,2:1,4:1),SMPTESafeAreas,CinemaGuides,
Anamorphic Desqueeze.
What’s in the Box
Included
Shinobi unit, 12V-15W AC power supply, Quick Start Guide
Construction note: Shinobi is designed to operate in ambient temperatures up to 40°C/104°F. If you wish to
extend the temperature of operation in high temperature conditions, set the TFT brightness to a minimum.
Please note: Specifications are subject to change without notice. All information correct at time of publishing.
Optional Accessories
Compatible optional accessories
Power Kit: 2 x NP-F Batteries, 1 x Charger, 1 x Power supply
AtomX 5” Cage for Shinobi(bySmallRig)
AtomX 5” Sunhood(compatiblew.Shinobi/NinjaV)
AtomX 5” Screen Protector (compatiblew.Shinobi/Ninja
V)
AtomX 10” Arm & Quick Release Plate (byLanparte)
Other:
Atomos HDMI cables
Xrite i1 Display Pro Calibrator and USB to Serial cable
AtomX 5” Accessory Kit
Warranty
1 Year from date of purchase
The main product, not including the IPS screen.

Atomos SHINOBI Specifications

General

Aspect ratio	16:9
LED backlight	-
Pixel density	427 ppi
Display diagonal	5.2 \
Display technology	IPS
Input voltage	6.2 - 16.8 V
Power supply type	Battery
Power consumption (max)	7 W
Power consumption (typical)	4 W
HDMI version	1.4
Headphone out	Yes
Product color	Black
Housing material	Polycarbonate (PC)
Connecting thread	1/4 \
Compatible memory cards	SD
Cables included	HDMI
Audio sampling rate	48 kHz
Supported video modes	720p, 2160p
Resolution at capture speed	1280x720@50fps, 1920x1080@23.98fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@59.94fps, 3840x2160@23.98fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@29.97fps, 4096x2160@23.98fps, 4096x2160@24fps, 4096x2160@25fps

Weight and Dimensions

Depth	31.5 mm
Width	151 mm
Height	91.5 mm
Weight	196 g
