Shogun Flame specs
Specications correct at time of printing E&OE
SHOGUN FLAME SPECIFICATIONS
Weight
Without batteries & media
650g / 22.9oz
With batteries & media
1094g / 38.6oz
Dimensions (W x H x D mm)
214x127x45mm,8.4x5x1.8”
Construction
High quality lightweight ABS Polycarbonate for durability
& portability
Built-in armor protection
Power
Operating power
10 - 24W
Compatible batteries
NP series and supporting accessories
Input voltage (battery)
6.2V to 16.8V
Battery time (based on 7.4V)
-
5200mAh-upto1.5hrs(monitor&record4K)
7800mAh-upto2.2hrs(monitor&record4K)
DC In
1 x DC in (6.2 - 16.8V)
Continuous power
* Patent pending
Primary-secondary battery system
Change batteries without losing power
Loop batteries continuously
Touchscreen
Size
7.1”
Resolution
1920 x 1200
PPI
325
AtomHDR
Yes
Bit depth
10-bit (8+2 FRC)
Brightness
1500nit (+/- 10%)
Aspect ratio
16:9 native
Color gamut
REC709 HDTV
Look up table (LUT) support
3DLUT(.cubeleformat)
Technology
SuperAtom IPS panel (capacitive touch), calibration to Rec.709
with optional calibration unit
Video input/loop out
HDMI
1 x HDMI (1.4b)
SDI
1x4K-SDI6GorHD-SDI3G/1.5G(SMPTE)
Signal
Uncompressed true 10-bit or 8-bit 422
(camera dependent)
Video output (play out)
HDMI
1 x HDMI (1.4b)
SDI
1x4K-SDI12G/6GorHD-SDI3G/1.5G(SMPTE)
Signal
Uncompressed true 10-bit or 8-bit 422
(playbackledependent)
Supported loop out formats
HDMI to HDMI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/120, 2160p 24/25/30
SDI to SDI
720p 50/60, 1080i 50/60
1080pSF 24/25/30
1080p 24/25/30/50/60/120*, 2160p 24/25/30
Video signal conversion
HDMI to SDI
720p 50/60, 1080i 50/60
1080p 24/25/30/50/60/120*, 2160p 24/25/30
SDI to HDMI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/120*, 2160p 24/25/30
Supported formats (Record & Playback)
4K
2160p 24/25/30
HD - high frame rate**
1080p120*, 1080p60/50
HD**
1080i60, 1080i50, 1080p30, 1080p25, 1080p24, 1080pSF24,
1080pSF25, 1080pSF30, 720p60, 720p50
4K UHD downscale for HD monitoring
Yes - loop-out & playback (not available in RAW)
Anamorphic de-squeeze
2x, 1.5x, 1.33x, Panasonic 8:3
Realtime hardware encoding
4K - DCI RAW 4096x2160 to
Supported cameras;
Sony FS700, FS7
CanonC300MKII,C500
Apple ProRes
HQ, 422, LT
DNxHR
HQX, HQ, SQ, LB
4K-UHD 3840x2160 8/10-bit 4:2:2 to
Apple ProRes
HQ, 422, LT
DNxHR
HQX, HQ, SQ, LB
1920x1080 8/10-bit 4:2:2 to
Apple ProRes
HQ, 422, LT
DNxHD
220x, 220, 145, 36
Onboard processing
Pulldown removal
24/25/30pSF > 24/25/30p (2:2 pulldown)
60i > 24p (3:2 pulldown)
Audio in/out (48kHz PCM audio)
HDMI
2 or 8ch 24-bit, camera dependent
SDI
12ch 48kHz 24-bit
Audio
2ch balanced XLR analog in/out
Dynamic range >90dB
Max signal level +24dBu
Max analog gain +52dB
48V Phantom Power for Mic
Remote start/stop
HDMI
Auto HDMI Trigger
Supported Protocols - Canon, Sony, Atomos Open Standard
SDI
SDI trigger camera selectable
Other
LANC control - Slave
Playback
Playlist
Yes
Genlock / LTC
Yes / Yes
Recording
Pre-roll record
Yes(HD8s,4K2s)
Custom timelapse
Yes
Meta data tagging
Yes (10 tags available)
Supported media
(Approved List Only)
4K/HD(50/60/120p)
SSD2.5”,HDD(7,200upto1080p60)
HD
SSD2.5”,HDD(5,400upto1080p30)
Master caddy case
Master Caddy II (included)
75mm x 105mm x 12mm
Master caddy dock
2.5”SATAtoUSB2.0/3.0
Supported applications
Supported Applications FCPX/FCP7+ / Media Composer
5.0+ / Premiere 5.5+
EDIUS 6.0+ / Vegas Pro 10+ / Lightworks /
Autodesk Smoke 2015
XMLsupport
FCPX XML native, FCP7 supported with conversion (Adobe
compatible)
Accessories included
Shogun Flame unit, Custom yellow HPRC case, Control
cable, XLR breakout cable, 2x NP-F750 5200mAh batteries,
Fast battery charger, SATA 3/2 to USB 3/2 HDD/SSD
docking station, DC to D-Tap coiled cable, Master Caddy
II x 5, 12V-3A AC adapter x 2 (Fast charger & DC power),
HDR sunhood
Optional extras
Atomos HDMI cable, Spyder calibration

Atomos Shogun flame Specifications

General

Display resolution	1920 x 1200 pixels
Audio system	48kHz, 24-bit
Product color	Black, Yellow
USB connectivity	Yes
Video capturing speed	120 fps
BNC input ports	1
HDD size	2.5 \
HDD interface	Serial ATA
Power consumption (max)	24 W
Cables included	DC, XLR-6.3 mm

Weight and Dimensions

Weight	650 g
Dimensions (WxDxH)	214 x 45 x 127 mm
