Digital Video Recorder
65
Search Button: Pressing the
SEARCH button enters the search mode, and pressing the button again exits the search
mode. When entering the search mode, video is paused. Pressing the (Play/Pause) button plays back video at regular
speed. The screen displays
when the DVR is in the Pause mode and the screen displays when the DVR is playing
back video.
Zoom Button: Pressing the
ZOOM button zooms in the current image on the screen.
Display Button: Pressing the
DISPLAY button toggles different display formats. The available formats are: 2x2, 1+5,
1+7, 3x3 and 4x4.
Group Button: Pressing the
GROUP button changes the screen from the current camera group to the next camera
group, and the screen displays page number.
You can use a mouse for convenient playback control. Position the mouse pointer on the playback screen, and the
following Record Table Search (Compact View Mode) screen will display. The individual controls on the toolbar
perform the following functions as described below:
Go to the previous image Play/Pause Go to the next image
Fast backward play Fast forward play
Searching Video
While in the search mode, pressing the
MENU button displays the following Search menu on the right edge of the screen.
Pressing the MENU button again hides the menu. You can navigate through menus and items by pressing the arrow
buttons.
Search
Go To
Bookmark
Display
Previous Group
Next Group
Alarm
Panic
Camera Menu
Export
Status
Data Source
Exit
Figure 47: Search menu.
NOTE: The Search menu also can be displayed by moving the mouse pointer on the right edge of the screen.
Search Menu
Search
Event Log Search: Selecting
(Search) → Event Log Search selects video from the event log. See the following
Event Log Search section for details.
