PROGRAMMING MENU
2E – Adaptive Start Profile
Options:
Early Acceleration
Constant Acceleration (default)
Late Acceleration
Description:
Selects which profile the EMX3 will use for an Adaptive Control soft start.
2F – Kickstart Time
Range:
0 – 2000 milliseconds
Default:
0000 milliseconds
Description:
Sets the kickstart duration. A setting of 0 disables kickstart.
2G – Kickstart Level
Range:
100% - 700% FLC
Default:
500%
Description:
Sets the level of the kickstart current.
CAUTION
Kickstart subjects the mechanical equipment to increased torque levels. Ensure the motor, load and couplings can
handle the additional torque before using this feature.
2H – Stop Mode
Options:
Coast To Stop (default)
TVR Soft Stop
Adaptive Control
Brake
Description:
Selects the stop mode.
2I – Stop Time
Range:
0:00 - 4:00 (minutes:seconds)
Default:
0 seconds
Description:
Sets the time for soft stopping the motor using timed voltage ramp or Adaptive Control. This also sets the total
stopping time when using brake.
If a main contactor is installed, the contactor must remain closed until the end of the stop time. Use one of the
programmable relays to control the main contactor.
2J – Adaptive Stop Profile
Options:
Early Deceleration
Constant Deceleration (default)
Late Deceleration
Description:
Selects which profile the EMX3 will use for an Adaptive Control soft stop.
2K – Adaptive Control Gain
Range:
1% - 200%
Default:
75%
Description:
Adjusts the performance of Adaptive Control. This setting affects both starting and stopping control.
NOTE
We recommend leaving the gain setting at the default level unless performance is not satisfactory.
If the motor accelerates or decelerates too quickly at the end of a start or stop, increase the gain setting by 5%~10%. If
the motor speed fluctuates during starting or stopping, decrease the gain setting slightly.
2L – Brake Torque
Range:
20% - 100%
Default:
20%
Description:
Sets the amount of brake torque the EMX3 will use to slow the motor.
2M – Brake Time
Range:
1 - 30 (seconds)
Default:
1 second
Description:
Sets the duration for DC injection during a braking stop.
<
NOTE
Parameter 2M is used in conjunction with parameter 2I. Refer to
Brake for details.
User Manual (710-04840-00M) | 47
